    SS304 7.5KW 3000kg/H Commercial Beer Brewing System

    Ask Lasest Price
    Brand Name : ZUNHUANG
    Model Number : ZHET-1000L
    Certification : CE ISO
    Price : USD5000-USD 25000
    Payment Terms : L/C, T/T, Western Union
    Supply Ability : 30sets per month
    Delivery Time : 30days
    • Product Details
    • Company Profile

    SS304 7.5KW 3000kg/H Commercial Beer Brewing System

    1000L commercial beer brewing equipment beer brewing system made by Zunhuang


    Product Description

    The whole beer equipment is consisted of Mash system,Fermentation system,Refrigeration system,Control system and CIP cleaning system. The tank of the system all adopts Red copper and S.S 304,and the system also have high automatic control capacity.


    Malt Milling

    Malt milling machine

    Stainless steel, Double roller

    Motor power:0.55-7.5KW

    Capacity:100- 3000(kg/h)

    Controlling input adjustable slide gate,equip motor, pulley, belt etc.

    Mash System

    Mash System

    Mash/ Lauter+ Brew Kettle/ Whirlpool + HLT

    Material: 304 stainless steel;

    Total volume: 1250L, effective volume 1000L;

    3. Shape: upper dish head, cylindrical barrel, shallow cone bottom;

    4. Manhole: glass manhole with sight light;

    5. Insulation material: polyurethane, rock wool insulation layer thickness 80mm;

    6. Heating method: Support Steam or heat up with hot water.

    7. Control system: The control cabinet automatically controls the temperature and controls the opening and closing of the upper stirring motor.


    Fermentation System

    Fermentation System

    1. Total volume: 1250L. Effective volume: 1000L;

    2. Material: food grade stainless steel SUS304;

    3. Cylinder design: cylinder, cylinder thickness: 3.0mm barrel outer thickness: 2.0mm;

    4. Manhole: the side manhole;

    5. The upper part is equipped with a hop add port, a breathing valve, and a carbon dioxide inflation port at the bottom.

    6. Insulation material, polyurethane foam, thickness: 80mm;

    7. Cooling method: Miller plate jacket double cooling

    8. Pressure: design pressure 3bar, working pressure 1.5-2bar;

    9. Lower cone design: cone seal 60° (for yeast discharge);

    10. Cleaning method: matching cip cleaning car uses fixed all-round rotating cleaning ball;

    11. Temperature measurement method: PT100 platinum resistance,

    Packaging & Shipping

    We can provide services to assist you in transporting equipment. We have regular cargo agents and are familiar with the transportation process, which can save you transportation costs and ensure the safety of equipment.

    Company Information

    Shandong Zunhuang Brewing Equipment Co., Ltd


    v 1. Shandong Zunhuang Brewing Equipment Co., Ltd, located in Jinan city(China, mainland), is a professional beer equipment, fruit wine equipment manufacturer in China. Shandong Zunhuang could provide the turnkey project for customer, including Production→ Inspection→ Packing & Shipping→ Installation &Training → After Sales.

    v 2. The equipment has exported more than 60 countries and regions, including the United States, Spain, Canada, Sweden, Denmark, Russia, India, Brazil, and other countries.
