    Micro 7 Bbl Brewing System HLT Fire Direct Heating Sus 304 Beer Fermenter

    Ask Lasest Price
    Brand Name : ZUNHUANG
    Model Number : ZH-10BBL
    Certification : CE ISO
    Price : Negotiation
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability : 15 sets per month
    Delivery Time : one month
    • Product Details
    • Company Profile

    Micro 7 Bbl Brewing System HLT Fire Direct Heating Sus 304 Beer Fermenter


    1. Total volume: 12BBL, Effectivevolume:10BBL

    2. Inside surface: SUS304, Thickness:3mm

    Outside surface: matte polishing stainless steel, Thickness:2mm;

    Thermal insulation material: rock wall, thickness: 80MM,

    Liner pickling passivation

    3. Materials: Stainless steel 304

    4. Heating method: steam heating/fire direct heating

    5. Feedstock method: it is designed by seal pump to pump out design, Mash pump with high power and low speed.

    6. Sealing method: Top pressure manhole feeding,

    7. Temperature measurement method: PT100 temperature probe

    8. Top stainless steel manhole, size: 350mm.

    9. Cleaning method: CIP Fixed rotate cleaning ball and sparage coil. top manhole,

    10. With:thermometer, level all necessary valves and fittings;

    11. Stainless steel legs, with screw assembly to adjust leg height.

    12. Matching valve accessories

    13. Processing technology: argon arc welding, external polishing, internal pickling passivation, no welding dead angle, to ensure fluid quality.

    14. The upper part is equipped with a reducer and a connecting mixer.

    15. The internal mixing device is equipped with the connection speed reducer and evenly heated.


    Micro 7 Bbl Brewing System HLT Fire Direct Heating Sus 304 Beer Fermenter

    Micro 7 Bbl Brewing System HLT Fire Direct Heating Sus 304 Beer Fermenter


    Micro 7 Bbl Brewing System HLT Fire Direct Heating Sus 304 Beer Fermenter

    Micro 7 Bbl Brewing System HLT Fire Direct Heating Sus 304 Beer Fermenter


    3. Fermentation System

    1. Totalvolume: 600L( 30% air volume),Effective volume:500L,

    2. cylinder tank; Inside surface: SUS304, Thickness:3mm,Outside surface: polishing stainless steel, Thickness:2mm, liner pickling passivation

    3.Thermal insulation material: Polyurethane (PU) foam,Insulation thickness: 80MM.

    4 Working pressure: 0.2Mpa;

    5. Bottom design: 60degree cone for easy to exist yeast. Liner pickling passivation

    6. Cooling method: Dimple cooling jacket(Cone and cylinder 2 zone cooling); Or screw type belt

    7. Cleaning system: Fixed-round rotary cleaning ball.

    8. Temperature measurement method: PT100 temperature probe

    9. Control system: PT100, temperature control;

    10. Manhole:Top Manhole

    11. With: CIP arm with spray ball, pressure gauge, mechanical pressure regulating valve, hops adding device and CO2 adding device,sampling valve, breath valve, Ice water solenoid valve, etc.
