    High Efficiency Mash Tank Brewhouse Equipment , Thick 500L Brewpub Equipment

    Ask Lasest Price
    Brand Name : ZUNHUANG
    Model Number : ZH-500L
    Certification : CE ISO
    Price : Negotiation
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability : 15 sets per month
    Delivery Time : one month
    • Product Details
    • Company Profile

    High Efficiency Mash Tank Brewhouse Equipment , Thick 500L Brewpub Equipment

    500L beer brewing equipment mash system mash tank for beer brewing brewery


    ZH-500L Mash System

    We are the beer brewing equipment manufacturer in China, all of our products have passed CE and ISO certification.Mainly supply 50L-5000L beer brewing system for brewery, pub, restaurant and home brewing amateur. If you have a good idea about start a brewery, and you don't know what to do in the process, you are welcome to communicate with our experienced sales staff. If you are looking for the most reasonable price, you are also welcome to contact us for the best quote.


    Mash System
    1. Total volume: 600L, Effectivevolume:500L
    2. Inside surface: SUS304, Thickness:3mm
    Outside surface: matte polishing stainless steel, Thickness:2mm;
    Thermal insulation material: rock wall, thickness: 80MM,
    Liner pickling passivation
    3. Materials: Stainless steel 304
    4. Heating method: steam heating
    5. Feedstock method: it is designed by seal pump to pump out design, Mash pump with high power and low speed.
    6. Sealing method: Top pressure manhole feeding,
    7. Temperature measurement method: PT100 temperature probe
    8. Top stainless steel manhole, size: 350mm.
    9.. Cleaning method: CIP Fixed rotate cleaning ball and sparage coil. top manhole,
    10. With:thermometer, level all necessary valves and fittings;
    11. Stainless steel legs, with screw assembly to adjust leg height.
    12. Matching valve accessories
    13. Processing technology: argon arc welding, external polishing, internal pickling passivation, no welding dead angle, to ensure fluid quality.
    14. The upper part is equipped with a reducer and a connecting mixer.
    15. The internal mixing device is equipped with the connection speed reducer and evenly heated.


    Information reference

    Effective Volume

    Total Volume


    500L

    600L


    Material

    Sus304


    Manhole

    Sus304 or Glass


    Heating meathed

    Eleceric or steam heating


    Cleaning Method

    Cip fixed cleaning rotary spray ball


    Processing technology:

    Weld


    Liner

    Argon arc welding, polishing at weld


    Pickling passivation


    Direct fire heating equipment



    Question and Answer:
    1, Are you a manufacturer?
    - Yes, our production experience has been more than 7 years
    2, Can you customize it according to my requirements?
    - Of course, just contact us and let me know your special requirements.
    3, Can you provide me more details?
    - No ploblem, tike tank argon arc welding welds, tank pickling passivated surfaces, external polishing details, etc.
    4, Can you help me calculate the shipping cost?
    Of course, you just need to tell me your port information.
